12kW High Voltage Solar Inverter Three Phase 120-800V Battery IP66 Pure Sine Wave MPPT Farm System
| Place of Origin | Guangdong, China |
|---|---|
| Brand Name | COENG |
| Certification | CE, IEC |
| Model Number | TP12KH |
| Minimum Order Quantity | 1 |
| Packaging Details | Carton, pallet |
| Delivery Time | 10-30working days |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20000piece/month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Size | 660mm*596mm*235mm | Battery Voltage | 120V-800V |
|---|---|---|---|
| Input Voltage | 1000V | OEM | Accept OEM |
| Inverter Type | Hybrid Solar Inverter | Protection Degree | IP66 |
| Gross Weight | 45kg/55kg | ||
| Highlight | 12kW High Voltage Solar Inverter,MPPT 12kW Solar Inverter,120-800V Battery Solar Inverter |
||
Product Description
Product Features.
1.Maximum efficiency of 98.4% and battery efficiency of 98.0%
2.Maximum battery charge/discharge current of 2*75A
3.Advanced parallel function
4.IP66 protection rating,ensuring adaptability to complex outdoor environment
5.Multiple built-in protections, with optional AFCl
6.Large MPPT current, compatible with high-power solar panels
|
|
Key Selling Points
-
Industrial-Grade Power & Efficiency
-
World-record efficiency (98.4% PV→AC) – maximizes ROI in high-irrigation regions.
-
Massive 45kW PV input + 45kW battery charging (dual-port) – harnesses abundant sunlight for factories/farms.
-
45kVA surge power (10s) – starts heavy machinery during outages.
-
-
Extreme Environment Resilience
-
IP66 rating (dust/waterproof) – superior to IP65 in sandstorms (Middle East) or monsoons (Asia).
-
-25°C to 60°C operation – survives Sahara heat or Andean cold.
-
4000m altitude support – for mines/farms in mountainous regions.
-
-
Grid Chaos Master
-
Ultra-wide voltage (277–520V) – stabilizes brownout-prone grids (Africa/LatAm).
-
<10ms transfer time – zero downtime for businesses during outages.
-
-
Future-Proof Battery Support
-
120–800V high-voltage batteries – compatible with next-gen lithium systems.
-
Dual battery ports – doubles charging speed (45kW) for large storage.
-
-
Global Compliance
-
Africa: NRS 097-2-1 (South Africa), VDE 4105.
-
LatAm: RD 1699 (Chile/Colombia), UNE 217002.
-
Middle East/Asia: AS 4777.2 (SEA), CEI 0-21.
-
Regional Dominance
| Region | Why It Wins | Top Applications |
|---|---|---|
| Africa | ▶️ 45kW solar input powers mines/factories during load-shedding. ▶️ IP66 resists Sahel dust. ▶️ NRS 097-2-1 certification. |
Mining (South Africa), Agribusiness (Kenya) |
| Southeast Asia | ▶️ 45kVA surge starts fish-freezing plants after typhoons. ▶️ IP66 withstands 100% humidity. ▶️ AS 4777.2 compliance. |
Seafood processing (Vietnam), Rubber factories (Indonesia) |
| Middle East | ▶️ 60°C operation in desert solar farms. ▶️ Dual MPPT optimizes uneven shading from sand. ▶️ 800V batteries reduce cabling costs. |
Oil field operations (Saudi), Desalination plants (UAE) |
| Latin America | ▶️ 4000m rating for Andean mines. ▶️ RD 1699 certification for industrial solar. ▶️ 30kW output powers coffee processing. |
Mining (Chile), Agro-industry (Colombia) |
Competitive Crushing Advantages
| Feature | TP Series Edge | Regional Impact |
|---|---|---|
| PV Input | 45kW (vs. 20–30kW competitors) | Powers factories in sun-rich regions. |
| Battery Charging | 45kW via dual ports (2× faster) | Slashes diesel dependency in off-grid Africa. |
| IP Rating | IP66 (vs. IP65 standard) | Survives sandstorms/monsoons (ME/Asia). |
| Certifications | 8+ global grid codes (NRS, RD1699, AS4777.2) | Faster approvals for industrial projects. |
