MPPT Pure Sine Wave On/Off Grid Hybrid Solar Inverter IP66 Three Phase 40V-60V 10kw 15kw Dual Output

  • MPPT Pure Sine Wave On/Off Grid Hybrid Solar Inverter IP66 Three Phase 40V-60V 10kw 15kw Dual Output
  • MPPT Pure Sine Wave On/Off Grid Hybrid Solar Inverter IP66 Three Phase 40V-60V 10kw 15kw Dual Output
  • MPPT Pure Sine Wave On/Off Grid Hybrid Solar Inverter IP66 Three Phase 40V-60V 10kw 15kw Dual Output
  • MPPT Pure Sine Wave On/Off Grid Hybrid Solar Inverter IP66 Three Phase 40V-60V 10kw 15kw Dual Output
  • MPPT Pure Sine Wave On/Off Grid Hybrid Solar Inverter IP66 Three Phase 40V-60V 10kw 15kw Dual Output
  • MPPT Pure Sine Wave On/Off Grid Hybrid Solar Inverter IP66 Three Phase 40V-60V 10kw 15kw Dual Output
  • MPPT Pure Sine Wave On/Off Grid Hybrid Solar Inverter IP66 Three Phase 40V-60V 10kw 15kw Dual Output
Place of Origin Guangdong, China
Brand Name COENG
Certification CE, IEC
Model Number TP10KL
Minimum Order Quantity 1
Packaging Details Carton, pallet
Delivery Time 10-30working days
Payment Terms L/C, T/T, Western Union
Supply Ability 20000piece/month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Size 425mm*710mm*290mm Battery Voltage 40V-60V
Input Voltage 600VDC OEM Accept OEM
Inverter Type Hybrid Solar Inverter Protection Degree IP65
Gross Weight 44kg
Highlight

Pure Sine Wave Hybrid Solar Inverter

,

Hybrid Solar Inverter IP66

,

On/Off Grid Hybrid Solar Inverter
Leave a Message
Product Description

Product Features.



1.Maximum efficiency of 99.9% and battery efficiency of 94.5%


2.Key components from international renowned brands

3.Advanced parallel function

4.Multiple built-in protections

5.Large MPPT current, compatible with high-power solar panels

6.IP66 protection rating, ensuring adaptability to complex outdoor environment

MODEL
TP10KL
TP15KL
Nominal input voltage
600V
600V
Mounting Method
Wall Bracket
Wall Bracket
Battery Type
Lithium-ion/Lead-acid
Lithium-ion/Lead-acid
Nos.of MPPT
2
2
Nominal Output Voltage
400V+20%
400V+20%
Battery Voltage Range
40V-60V
40V-60V
Rated Grid Frequency
50Hz/60Hz
50Hz/60Hz
Automatic switch time
<10ms
<10ms
Max. DC input power
20kW
30kW
IP class
IP66
IP66
Max. output apparent
11KVA
17.5KVA
Weight
44Kg
44Kg
Dimensions (W*H*D)
425mm*710mm*290mm
425mm*710mm*290mm
Warranty
5 Years/10 Years (Optional)
5 Years/10 Years (Optional)
Display
LCD and App
LCD and App
